SM10 Glass 1510 Straight-line Double Sides Seaming Processing line With 10 Spindles

  • ENKONG&ENKONGS
  • MADE IN CHINA
  • 30DAYS AFTER DEPOSIT
  • 30SETS/MONTH
  • IRON PALLET AND FOAM PACKAGING
  • T/T OR L/C AT SIGHT
  • SGS,CE
  • GUARANTEE 14 MONTHS AFTER DELIVERY
1. The processing speed is 1-25m/min. 2. The main transmission adopted timing belt (Italian branded) 3. It is the best supporting machine for large-scale furniture and architectural decoration glass processing.




Basic Configuration:

1. Ball screw(Width adjustment): Taiwan HINWIN/TBI/PMI

2. Linear guide: Taiwan HINWIN/TBI/PMI

3. base, movable & fixed bridge, conveyor plate: high-quality steel plate welding after heat treatment finishing

4. Water tank material: Stainless steel SUS201

5.Timing belt: Megadyne,Italy

6. Operation: PLC + touch screen control. Fully automatic PLC computer control, touch screen user friendly interface, easy to operate.


double seaming machine


Electrical Parts

Item

Manufacture

Origin

Low-Voltage apparatus

Schneider

France

button

Takahashi

CHINA

Inverter

Delta

Taiwan, China

transformer

erbian

China

Encoder

Koyo

Japan

PLC

Delta / Wing Hong

Taiwan, China

touch screen

Delta

Taiwan, China

Servo system

Delta / Wing Hong/

Taiwan, China



The main gear box shaft sleeve adopts through sleeve structure, using high precision roller bearings, stable and reliable operation, long service life, reduce maintenance cost. Servo motor transmission is also available for option.



1. Standard Model: High performance ABB motors first one adopts 3kw. Inside of the sliding part adopt the bronze nut work with adjustment screw rod to reduce the gap, more flexible and durable.

2. Mechanical (belt) transmission: with 4200rpm mechanical transmission by belt driven. Spindles shaft rotation at 4200rpm/min. The shaft can tolerant up to 12000rpm/min maximum, however, only using 1/3 of total speed capacity. The processing speed is upon 15m/min with polishing. Grinding ability has improved

3. Mechanical (belt) transmission with Servo driven In-feed arrangement: Fully automatic wheel adjustment. Precise calculation between wheel and material. Avoiding uneven grinding caused by human error. Stepping into the next automation level.
